Deploy Ollama on Kubernetes with GPU
- 3 minsOllama is an open-source tool and runtime environment for running Large Language Models (LLMs) locally, typically on your own machine. It functions as a CLI and server runtime for managing and executing LLMs, downloading and running GGUF-format models optimized for CPU/GPU processing.
I deployed Ollama on a small Kubernetes cluster equipped with NVIDIA H200 GPUs, utilizing Kai-Scheduler to allocate fractional GPU resources.
Prerequisites
- Functioning Kubernetes cluster
- Worker nodes with GPU installed and configured
Step 1: Deploy Ollama
Create a deployment manifest (tiny-ollama.yaml) with Kai-Scheduler for fractional GPU allocation (0.5 GPU):
apiVersion: v1
kind: Namespace
metadata:
name: ollama
---
apiVersion: apps/v1
kind: Deployment
metadata:
name: ollama
namespace: ollama
spec:
strategy:
type: Recreate
selector:
matchLabels:
name: ollama
template:
metadata:
labels:
name: ollama
runai/queue: test
annotations:
gpu-fraction: "0.5"
spec:
schedulerName: kai-scheduler
containers:
- name: ollama
image: ollama/ollama:latest
env:
- name: PATH
value: /usr/local/nvidia/bin:/usr/local/cuda/bin:/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin
- name: LD_LIBRARY_PATH
value: /usr/local/nvidia/lib:/usr/local/nvidia/lib64
- name: NVIDIA_DRIVER_CAPABILITIES
value: compute,utility
ports:
- name: http
containerPort: 11434
protocol: TCP
tolerations:
- key: nvidia.com/gpu
operator: Exists
effect: NoSchedule
Apply the manifest:
$ kubectl apply -f tiny-ollama.yaml
namespace/ollama unchanged
deployment.apps/ollama created
service/ollama unchanged
Verify deployment:
$ kubectl get deploy -n ollama
NAME READY UP-TO-DATE AVAILABLE AGE
ollama 1/1 1 1 2m24s
$ kubectl get pod -n ollama
NAME READY STATUS RESTARTS AGE
ollama-5547f5dfd5-5frfp 1/1 Running 0 2m1s
Step 2: Install Ollama Client
Access the pod and install the Ollama client:
$ kubectl exec -it ollama-5547f5dfd5-5frfp -n ollama -- bash
root@ollama-5547f5dfd5-5frfp:/#
root@ollama-5547f5dfd5-5frfp:/# apt update -y
root@ollama-5547f5dfd5-5frfp:/# apt install curl -y
Download and extract Ollama:
root@ollama-5547f5dfd5-5frfp:/# curl -L https://ollama.com/download/ollama-linux-amd64.tgz -o ollama-linux-amd64.tgz
root@ollama-5547f5dfd5-5frfp:/# tar -C /usr -xzf ollama-linux-amd64.tgz
Execute the Llama 3.2 3B model:
root@ollama-5547f5dfd5-5frfp:/# ollama run llama3.2:3b-instruct-fp16
pulling manifest
pulling e2f46f5b501c: 100%
pulling 966de95ca8a6: 100%
pulling fcc5a6bec9da: 100%
pulling a70ff7e570d9: 100%
pulling 56bb8bd477a5: 100%
pulling 1bc315994ceb: 100%
verifying sha256 digest
writing manifest
success
>>> Send a message (/? for help)
Interact with the model at the prompt:
>>> Who are you?
I am an artificial intelligence model, which means I'm a computer program designed to
simulate human-like conversations and answer questions to the best of my knowledge.
I don't have personal experiences, emotions, or consciousness like humans do.
>>> what is llm?
LLM stands for Large Language Model. It refers to a type of artificial intelligence (AI)
model that uses deep learning techniques to process and understand human language.
Enable verbose mode to see performance metrics:
>>> /set verbose
>>> Tell me a knock knock joke in a single line
Knock, knock!
total duration: 247.083012ms
load duration: 88.303796ms
prompt eval count: 3182 token(s)
prompt eval duration: 32.244837ms
prompt eval rate: 98682.47 tokens/s
eval count: 6 token(s)
eval duration: 49.158717ms
eval rate: 122.05 tokens/s
Monitor GPU usage during queries:
$ gpustat -i
gpun1 Tue Jul 1 20:54:59 2025 570.133.07
[0] NVIDIA H200 NVL | 40'C, 0 % | 604 / 143771 MB |
[1] NVIDIA H200 NVL | 48'C, 62 % | 8701 / 143771 MB | root(8088M)
The deployment successfully establishes a local ChatGPT-like environment running within the Kubernetes cluster.
